Anti-Glare Recessed LED Wall Washer Spotlight FST-SP-QL01
Product Specifications
| Installation Method | Recessed |
|---|---|
| Application | Feature Wall / Corridor / Hotel / Retail Store |
| CRI | Ra90 / Ra98 Optional |
| IP Protection Rating | IP20 |
| Beam Angle | 15° / 24° / 36° |
Product Overview
Where This Recessed Wall Washer Works Best
FST-SP-QL01 is a recessed LED wall washer spotlight designed to spread light smoothly across vertical surfaces. Its asymmetric optical direction helps move more light toward the wall instead of creating a small bright circle directly below the fixture. The deep anti-glare structure also improves visual comfort when the light is installed in corridors, hotels, retail stores, galleries, showrooms or residential feature-wall areas.
Five sizes cover 5W to 40W, with cut-outs from 55mm to 120mm. Ra90 and optional Ra98, 3000K, 3500K or 4000K, and different beam options can be selected according to the wall height, fixture spacing and required lighting effect.
How to Select the Configuration
| Item | Options | Selection Guidance |
|---|---|---|
| Power | 5W / 10W / 20W / 30W / 40W | Choose according to wall height, fixture spacing and required brightness. |
| Cut-out | 55mm to 120mm | Confirm the exact opening before ordering, especially for replacement projects. |
| Beam angle | 15° / 24° / 36° / 55° depending on size | Availability varies by wattage; match the optic to the wall distance and target coverage. |
| CRI | Ra90 / Ra98 optional | Ra98 is suitable for artwork, material displays and color-sensitive surfaces. |
| CCT | 3000K / 3500K / 4000K | Select according to surface color and the atmosphere of the space. |
What to Confirm Before Ordering
- Wall height, fixture-to-wall distance and planned spacing.
- Power, product size and ceiling cut-out.
- Beam angle availability for the selected wattage.
- CCT, Ra90 or Ra98, and LED source.
- Driver and dimming requirements.
- Quantity and OEM label or packaging details.
For another asymmetric recessed option, compare the FST-OC03 wall washer. You can also browse all LED spotlights or contact FANSEN with the wall dimensions and lighting plan.
Frequently Asked Questions
How is a wall washer different from a standard spotlight?
A standard spotlight produces a centered beam, while this wall washer directs light toward a vertical surface to create more continuous wall illumination.
How far should the fixture be from the wall?
The correct distance depends on wall height, beam option and fixture spacing. Important projects should be checked with a sample or lighting calculation.
Are all beam angles available for every wattage?
No. The available beam angles vary by size and power, so the selected wattage and optic must be confirmed together.
Can Ra98 be supplied?
Yes, Ra98 is optional according to the selected LED source and project requirement.
What is the usual MOQ?
The normal MOQ is 100 pieces per confirmed configuration. Samples can be arranged before bulk production.
